parameter:
|
model no. |
qy301 |
qy301a |
|
lifting capacity |
4t |
4.5t |
|
max lifting height |
1820mm |
1820mm |
|
minimum height |
95mm |
95mm |
|
lifting time |
≤50s |
≤50s |
|
overall width |
3410mm |
3410mm |
|
overall height |
3590mm |
3590mm |
|
motor voltage |
380v/220v |
380v/220v |
|
motor power |
2.2kw |
2.2kw |
|
package size |
3690x465x735mm |
3690x465x735mm |
features:
1. the column with 8 bending
2. integral type carriage
3.manual two-side lock release system
4.dual balancing cable remote control for precise carriage movements
5.4×4 high load bearing chain,safe and reliable
6. every cylinder passes the pressure test
7. adopt quality power unit, more endurable,running safely and reliably
8.pass 115% dynamic overload test and 150% static overload test.
