parameter:
model no. |
qy302 |
lifting capacity |
4t |
max lifting height |
1800mm |
minimum height |
123mm |
lifting time |
≤50s |
overall width |
3286mm |
overall height |
3970mm |
motor voltage |
380v/220v |
motor power |
2.2kw |
package size |
3690x465x735mm |
features:
1.column thickness is 6mm and material is q345 steel
2.inverted cylinder, without chain, simple structure, easy going, lifting steadily
3. single side electric release
4.three-section asymmetrical arm
5.aluminum housing motor to prevent the motor from overheating
6.using middle and upper limit to ensure safe operation
7.standard spiral round tray
8.every cylinder passes the pressure test
9.24v safety control system
10.pass 115% dynamic overload test and 150% static overload test.
