parameter:
|
model no. |
qy802 |
|
lifting capacity |
3.5t |
|
max lifting height |
2050mm |
|
minimum height |
220mm |
|
lifting time |
≤50s |
|
platform width |
570mm |
|
platformlength |
1500-1940mm |
|
oil pressure |
0.6-0.8mpa |
|
motor voltage |
380v/220v |
|
motor power |
2.2kw |
|
package size |
1530x630x500mm |
features:
1.support arm using high strength q345 steel, thickness 20mm
2. four-cylinder drive structure, super power
3.double oil system
4. upper limit function to ensure safe operation
5.equipped with security lock, pneumatic release
6. platform installed non-slip rubber pad
7. every cylinder passes the pressure test
8. 24v safety control system
9.pass 115% dynamic overload test and 150% static overload test.
