parameter:
|
model no. |
qy501 |
|
main lift lifting capacity |
4t |
|
sub-lift lifting capacity |
3.5t |
|
main lift lifting height |
1850mm |
|
sub-lift lifting height |
450mm |
|
minimum height |
185mm |
|
lifting time |
≤50s |
|
main lift platformlength |
4500mm |
|
sub-lift platformlength |
1500mm |
|
main lift platformwidth |
600mm |
|
sub-lift platformwidth |
600mm |
|
oil pressure |
0.6-0.8mpa |
|
motor voltage |
380v/220v |
|
motor power |
2.2/3.0kw |
features:
1. designed for ground installation, easy to install
2.design for wheel alignment, vehicle maintenance
3.embedded secondary lifting
4.integral molding platform
5.high strength solid steel support arm
6.six-cylinder drive, every cylinder passes the pressure test
7.side slide can be left and right and backward sliding, easy to eliminate the gap of rear wheel
8.the corner plate position with a large buckle slot, adjustable
9.pneumatic release device minimizes the noise of machine operating
10.24v safety control system
11.pass115% dynamic and 150% static test.
