parameter:
|
model no. |
qy602 |
|
main lift lifting capacity |
3.5t |
|
sub-lift lifting capacity |
3.5t |
|
main lift lifting height |
1800mm |
|
sub-lift lifting height |
500mm |
|
minimum height |
335mm |
|
lifting time |
≤50s |
|
main lift platformlength |
4500mm |
|
sub-lift platformlength |
1500mm |
|
main lift platformwidth |
600mm |
|
sub-lift platformwidth |
600mm |
|
oil pressure |
0.6-0.8mpa |
|
motor voltage |
380v/220v |
|
motor power |
2.2kw |
features:
1. underaround installation
2.design for wheel alignment, vehicle maintenance
3.embedded secondary lifting
4. integral molding platform
5.four-cylinder drive, every cylinder passes the pressure test
6.side slide can be left and right and backward sliding, easy to eliminate the gap of rear wheel
7.the corner plate position with a large buckle slot, adjustable
8.pneumatic release device minimizes the noise of machine operating
9.24v safety control system
10.pass dynamic and 150% static test.
