parameter:
|
model no. |
803 |
|
lifting capacity |
3.5t |
|
max lifting height |
2130mm |
|
minimum height |
330mm |
|
lifting time |
≤50s |
|
platform width |
550mm |
|
platformlength |
1540-1740mm |
|
oil pressure |
0.6-0.8mpa |
|
motor voltage |
380v/220v |
|
motor power |
2.2kw |
|
packing size |
1530×630×500mm |
features:
1.newly designed extension table and in-ground construction, could be used for more model
2.square tube support arm
3.upper limit function to ensure safe operation
4.equipped with security lock, pneumatic release
5.every cylinder passes the pressure test
6.24v safety control system
7.pass 115% dynamic overload test and 150% static overload test.
